DC Power Moller(MDR)

DC Power Moller (MDR)

MDR is the abbreviation of Motor Driven Roller, or Motorized Drive Roller as defined in CEMA.

ITOH DENKI developed DC version Power Moller incorporating brushless dc motor in 1988, then developed in 1999,the Power Moller 24 having high speed, high torque and diagnosis capability. Further efforts were made to integrate more intelligence including variable speed, acceleration/deceleration, and built in control logic. We at ITOH DENKI call those DC version Power Moller 24 as "MDR".

Product sheet

Brushless DC Motor

Standard type

Roller diameter(mm) Power Moller model Introduction
φ38.0 PM380LS pdf
φ42.7 PM427LS pdf
φ48.6 PM486FE pdf
φ50 PM500FE pdf
φ57 PM570FE pdf
φ60.5 PM605FE pdf

High torque type

Roller diameter(mm) Power Moller model Introduction
φ48.6 PM486FP pdf
φ50 PM500FP pdf

Integral motor driver type

Roller diameter(mm) Power Moller model Introduction
φ48.6 PM486XE
PM486XP
pdf
φ50 PM500XE
PM500XP
pdf
φ57 PM570XE
PM570XP
pdf
φ60.5 PM605XE
PM605XP
pdf

Ultra high torque type

Roller diameter(mm) Power Moller model Introduction
φ57 PM570KT pdf
φ60.5 PM605KT pdf

Blushless DC Motorized Pulley

Roller diameter(mm) Power Moller model Introduction
φ32 PM320HS pdf

Driver card

Standard Driver

CBL-402 pdf
CB-016 pdf
CBK-109 pdf
CB-018 pdf

Built-in logicZero Pressure Accumulation Video

HB-510 pdf
HBM-604 pdf
HBK-608

Network based

IB-C02B (CC-Link) pdf

Network +Local Logic id Linx

IB-E03B (EtherNet/IP)
IB-E04F (EtherNet/IP)
pdf
IB-P01F (ProfiNET)
IB-P02F (ProfiNET)

IB-P03 (ProfiNET)

Success story

USPS Chicago O'Hare AMC (USA) pdf
Chivas Brothers (UK) pdf
VOW Distribution Center (UK) pdf
Euronegoce (France) pdf
Royal Mail (UK) pdf
ISOLA Laminated Systems (USA) pdf

MDR Selection tool
